CXJ centrifugal oil filter

Purpose:Disc type centrifugal oil filters are mainly used for the purification treatment of gasoline, diesel, and heavy marine fuel. They can effectively remove water and impurities from the oil, clarify and purify it, reduce the wear and tear of diesel engines and other machines, and extend the ser...

Online Inquiry Contact Us

Product Details

Purpose:

Disc type centrifugal oil filters are mainly used for the purification treatment of gasoline, diesel, and heavy marine fuel. They can effectively remove water and impurities from the oil, clarify and purify it, reduce the wear and tear of diesel engines and other machines, and extend the service life of the engine. It can also be applied to the clarification and purification treatment of lubricating oil, hydraulic oil, and turbine oil, slowing down the wear of lubrication system machines and extending the service life of machines and oils. This model can also be applied to the separation of heterogeneous suspensions or emulsions in other fields.

Features:

1. High separation factor centrifugation technology achieves ultra-high efficiency in impurity removal and dehydration, which is 3-5 times higher than traditional filtration efficiency.

2. The ultra-high speed separator can continuously separate solid impurities and moisture from the medium to be purified.

3. Running vibration, minimal noise, automatic impurity removal, continuous and efficient.

4. The contact part between the drum and the oil is made of stainless steel material

5. The machine has a compact structure, easy mobility, simple operation, and is safe and reliable. It is particularly suitable as a supporting equipment for ship maintenance, reducing the labor intensity of crew and ensuring the normal operation of machinery. Manufacturing and acceptance comply with GB/T5745-2002 "Marine Disc Separators"

Principle:

By utilizing the different densities of liquid and solid, turbid liquid forms a circular ring with multiple components of different densities under the action of centrifugal force in a high-speed rotating drum. The solid particles with the highest density move outward and accumulate on the peripheral wall of the drum, while the light phase liquid is in the innermost layer. There are discs inside the drum, which divide the drum space into many thin separation spaces, greatly reducing the settling distance and improving and enhancing the separation effect. Any extreme particle between two discs that reaches the inner surface of the disc can be separated. The separated oil is pumped out by the light phase pump, water is pumped out by the heavy phase pump, and impurities are discharged from the discharge pump.
